Features
RECORD-BREAKING PERFORMANCE
New Holland CR combines hold the world record for capacity in both wheat and soybeans. In 2014, the CR10.90 harvested 29,308 bushels of wheat in less than eight hours, obliterating the previous harvesting record.
BEST-IN-CLASS GRAIN AND STRAW QUALITY
The multi-pass action of the Twin Rotor® design releases grain quickly and gently for low grain damage and loss. Gentle, in-line crop flow creates straw that’s perfect for baling.
GET THE INTELLISENSE™ ADVANTAGE
The IntelliSense™ combine automation system optimizes the CR series combine settings every 20 seconds so you get the highest possible throughput and lowest grain loss.
SAVES ON FUEL AND LABOR COMPARED TO COMPETITION
When compared to competitive combines in independent tests, CR combines use less fuel, lose less grain and harvest more quickly and efficiently to increase your profitability.
THE WORLD'S HIGHEST CAPACITY COMBINE
CR combines break records in capacity and performance and provide you with a higher return on investment. They help you achieve higher efficiency and productivity, using innovations like the award-winning IntelliSense™ combine automation system, Dynamic Flow Control™ remotely adjustable rotor vanes, deep cut Dynamic Feed Roll™ technology and patented Opti-Spread™ Plus super-wide residue spreading.
Features may include:
ULTIMATE EASE IN THE HARVEST SUITE™ ULTRA CAB
New Holland designed the Harvest Suite Ultra cab with more comfort and ease so you stay refreshed and work with precision, even during long days and nights harvesting. This 131-cubic-foot cab gives you plenty of space, and at 73 decibels, it is still the quietest cab on the market.
EFFORTLESSLY MAXIMIZE YOUR PERFORMANCE
Intelligent and intuitive automation saves time and enhances harvesting performance. The CommandGrip™ multi-function handle is your right-hand harvesting man. You control all key machine and header parameters, including header height, reel position and unloading engagement. The right-hand console contains less frequently used functions, which are laid out in an ergonomic and logical manner. You monitor machine functions at a glance courtesy of the color IntelliView™ IV display. Two USB charging ports are included at the front of the right-hand console for your convenience.
EFFICIENT FEEDING THAT INCREASES CAPACITY AND IMPROVES PROTECTION
The CR Series feeding system features four chains with connecting slats for improved crop flow and even smoother feeding into the Twin Rotor® threshing system.
UNRIVALED TWIN ROTOR® GRAIN QUALITY
New Holland invented the Twin Rotor® concept more than 44 years ago and has refined this evolving technology so that it delivers unmatched efficiency, capacity and grain quality. It’s also a design that is extremely flexible, making it easy to match a CR Series combine to various crops, conditions and operations.
THE CLEANEST GRAIN SAMPLE
Best-in-class grain quality and the industry’s cleanest grain sample … it must be the CR REVELATION. Don’t just take our word for it. In comparative grain sample tests, Twin Rotor® technology beat the competition hands down. The result: a minuscule 0.2% broken grain.
Specifications
| MODEL | CR9.90 Aggressive Shake |
| Combine Class | |
| Combine Class | 9 |
| Harvest Suite™ Ultra cab glass area | |
| Harvest Suite™ Ultra cab glass area (ft.² (m²)) | 68 (6.3) |
| Halogen lighting pack | Standard |
| LED lighting pack | Optional |
| LED far distance lights | Optional |
| Standard cloth trimmed seat with air-suspension | Standard |
| Deluxe cloth trimmed heated air-suspension seat with Active Ventilation | Optional |
| Leather trimmed heated air-suspension seat with Active Ventilation | Optional |
| IntelliView™ IV monitor with adjustable position | Standard |
| 2nd IntelliView™ IV monitor | Optional |
| Viewing cameras | Optional |
| Automatic climate control and coolbox | Standard |
| Integrated portable fridge under instructor seat | Standard |
| MP3 Bluetooth® radio (hands-free phone calls) | Optional |
| Satellite radio with Bluetooth® (hands-free phone calls) | Optional |
| Heated Floor Mat | Optional |
| Optimum cab noise level - ISO 5131 (dB(A)) | 73 |
| New Holland Precision Land Management Systems | |
| IntelliSteer™ ready automatic guidance system | Standard |
| IntelliCruise™ 2 feed rate control system | Optional |
| IntelliSense™ Combine automation system (Includes Grain Cam™ Sensor) | Optional |
| New Holland FieldOps™ Telematics & File Transfer | Standard |
| Yield and moisture sensor and desktop software | Standard |
| Automatic Header Control Systems | |
| Terrain Tracer™ system / Autofloat™ system | Standard |
| Straw Elevator | |
| Number of chains | 4 |
| Remote Front Face Adjustment Angle | Optional |
| ASP system - Advanced Stone Protection™ | Standard |
| Deep Cut DFR system - Dynamic Feed Roll™ | Optional |
| Twin Rotor® Technology | |
| S³ rotors | Standard |
| Twin Pitch rotors | Optional |
| Twin Pitch Plus rotors | - |
| Rotor diameter / length (in. (cm)) | 22 / 104 (56 / 264) |
| Manual adjustable rotor vanes | Optional |
| Dynamic Flow Control™ Remote adjustable rotor vanes | Optional |
| Automatic concave reset | Standard |
| Cleaning | |
| Self-leveling cleaning shoe with Opti-Fan™ | Standard |
| Opti-Clean™ cleaning system | - |
| Enhanced aggressive shake shoe cleaning system | Standard |
| Remote Presieve opening | Optional |
| Total sieve area under wind control (in.² (m²)) | 10,075 (6.5) |
| Grain tank and Unloading | |
| Grain tank manual folding extensions, standard (optional) (bu.) | 410 |
| Folding covers capacity (bu.) | 410 |
| Unloading speed (bu./sec.) | 4.5 |
| Folding unloading tube | Optional |
| Pivoting unloading tube spout | Optional |
| Residue Management | |
| Integrated straw chopper | Standard |
| Chaff spreader with remote controlled RPM | Standard |
| PSD (Positive Straw Discharge) belt | Optional |
| Remote chop / drop selection | Optional |
| Opti-Spread™ residue management | Optional |
| Engine* Compliant with Tier 4 Emissions Regulations | |
| Engine* Compliant with Tier 4 Emissions Regulations | FPT Cursor 13 |
| ECOBlue™ Hi-eSCR system (Selective Catalytic Reduction) | Standard |
| Injection system | Common Rail |
| Gross engine power @ 2100 rpm (CV) (hp (kW)) | 544 (406) |
| Maximum engine power @ 2000 rpm (CV) (hp (kW)) | 600 (447) |
| Fuel Tank | |
| Diesel capacity / DEF capacity (gal. (L)) | 340 (1287) / 42 (159) |
| Transmission | |
| 2-Speed (Field & Road) gearbox | Standard |
| Differential lock | Optional |
| Road transport speed 19 / 25 mph (30 / 40 kph) | Standard / Optional |
| Factory installed SmartTrax™ system | Optional |
| Dimensions and Weight | |
| Weight - Standard version less header (lbs. (kg)) | 42,236 (19,158) |
| Dimensions with traction wheels** | 900 / 75 R32 |
| Wheelbase (ft. in. (m)) | 12" 4' (3.76) |
| Maximum height - transport (ft. in. (m)) | 13' (3.96) |
| Maximum width (ft. in. (m)) | 13' (3.96) |
| Maximum width - transport (ft. in. (m)) | 10' 10" (3.3) |
| Specifications | |
| Grain tank, extensions/covers, bushels | 410 |
| Rated engine power @ 2100rpm, hp | 544 (406) |
| Maximum engine power @ 2000rpm, hp | 600 |
