Features
Helps you prepare the ideal seedbed by cutting and sizing residue, eliminating clumps, and loosening packed soil.
- Standard features: Adjustable 88½” tongue with base hitch and tongue jack, 1½” square, high-carbon, cold-rolled steel axles, 24″ diameter x ¼” thick plain blades with diminishing leveling blades
- Optional blade diameters and thicknesses are available
- Backup blades provide added support for working blades
- Safety features: Safety chains, slow-moving placard, and light kits
- Optional equipment: Cutout blades in place of plain blades or feathering blades for rear gang
- Equipped with ³⁄₁₆” x 6½” x 8” high-carbon steel, replaceable, adjustable scraper blades mounted on bars of 2½” x 2½” square tubing; the scrapers are attached to the 2½” x ½” thick arms with heavy-duty U-bolts
- Includes heavy-duty bearing risers or Shock Absorber Bearing Riser
- Dual wheels provide improved flotation
- Positive screw-type depth control maintains set cutting depth
- Wear and zerk guards protect bearing housings and grease fittings
- Heavy-duty 3,000 PSI hydraulic cylinders adjust cutting depth and raise the disc for transport
- Features outriggers of 16’6″ and 18’0″
- Disc gangs feature maintenance-free bearings with three-year warranty; bearings eliminate possibility of contamination and need for re-lubrication
- Frame clamps help ensure proper frame alignment, even under the toughest field conditions
- Leveling spring and multiple tongue settings allow adjustments for changes in soil conditions
- Weights of 164 to 208 pounds per blade
Specifications
50″ Main Frame
| Model | F42-2224 | F42-2424 | F42-2824 | F42-3224 |
| Cutting Width* | 8'3″ | 9'0″ | 10'6″ | 12'0″ |
| No. of Disc Blades | 22 | 24 | 28 | 32 |
| No. of Bearings | 8 | 8 | 8 | 10 |
| Approx. Engine HP | 95-122 | 108-142 | 122-162 | 135-190 |
| Approx. Weight lbs.** | 4,146 | 4,290 | 4,785 | 5,223 |
86″ Main Frame (B)
| Model | F42B-3224 | F42B-3624 | F42B-4024 | F42B-4424*** | F42B-4824*** |
| Cutting Width* | 12'0″ | 13'6″ | 15'0″ | 16'6″ | 18'0″ |
| No. of Disc Blades | 32 | 36 | 40 | 44 | 48 |
| No. of Bearings | 10 | 12 | 12 | 14 | 16 |
| Approx. Engine HP | 149-203 | 162-216 | 182-236 | 203-257 | 216-270 |
| Approx. Weight lbs.** | 6,424 | 6,708 | 7,008 | 8,057 | 8,341 |
*Transport width is cutting width plus 6″.
**To calculate weight/blade, divide the approximate weight of the model by the number of disc blades.
***Equipped with auxiliary frames, clamps, and 8-hole hubs with 15″ x 10″ 8-hole wheels.
Specifications subject to change without notice.
